Slicer Technical Specifications
| Technical Parameter | Specification | Physical Parameter | Specification |
|---|---|---|---|
| Product Name | Auto Mutton Slicer | Gross/Net Weight | 263.5/215.0 kg |
| Power Supply | 110V-60Hz / 220V-50Hz | Power Consumption | 750W × 2 |
| Slice Thickness | 0.2-20 mm | Machine Material | Aluminum-Magnesium Alloy |
| Blade Diameter | 360 mm | Blade Material | Imported Stainless Steel |
| Slice Width | 335 mm | Packaging Dimensions | 1120×835×1650 mm |
Core Parameter Analysis
Performance Features
- Power Adaptability: Dual voltage design (110V/230V), suitable for different industrial power environments
- Slicing Precision: Thickness range 0.2-20mm, meeting fine processing requirements
- Cutting Capacity: 335mm effective slicing width, supporting large material processing
Material Configuration
- Main Structure: Aluminum-magnesium alloy body, balancing strength and lightweight
- Core Components: Imported stainless steel blades, ensuring cutting sharpness and durability
- Power Configuration: Dual 750W motor design, providing sufficient power support
Logistics Information
- Weight Control: Net weight 215kg, gross weight 263.5kg, facilitating transportation and installation
- Packaging Specifications: 1120×835×1650mm standard industrial packaging
Application Recommendations
This slicer is suitable for food processing, medicinal material slicing, industrial material segmentation, and other fields. Its precise thickness adjustment and wide cutting capacity can meet the processing needs of various industries. It is recommended to select the appropriate slice thickness parameters based on specific material characteristics.
Hualing Slicer Series Technical Specifications
Product Comparison Table
| Model | Power Configuration | Blade Diameter | Slice Thickness | Slice Width | Gross Weight | Net Weight | Package Dimensions |
|---|---|---|---|---|---|---|---|
| HB-350 | • 380V/50Hz/750w×2 • 230V/50Hz/750W • 110V/60Hz/750W |
363mm | 0.2-20mm | 335mm | 263.54kg | 215kg | 1100×800×1590mm |
| HB-330A | • 380V/50Hz/750w×2 • 230V/50Hz/750W • 110V/60Hz/750W |
385mm | 0.2-20mm | 350mm | 265.59kg | 217.05kg | 1100×800×1590mm |
| HB-300 | • 230V/50Hz/750W • 110V/60Hz/750W |
300mm | 0.2-14mm | 240mm | 69kg | 60kg | 950×750×1200mm |
| HB-330 | • 230V/50Hz/750W • 110V/60Hz/750W |
330mm | 0.2-14mm | 240mm | 81kg | 61kg | 950×750×1200mm |
| HB-320 | • 380V/50Hz/370w×2 • 230V/50Hz/370W • 110V/60Hz/370W |
320mm | 0.2-16mm | 230mm | 103.06kg | 87.24kg | 812×642×880mm |
Technical Specifications Analysis
Power Configuration
- High-power models (750W): HB-350, HB-330A, HB-300, HB-330
- Standard-power model (370W): HB-320
- Voltage compatibility: All models support multiple voltage standards (110V/230V/380V)
Performance Specifications
- Blade diameter range: 300-385mm
- Slice thickness range: 0.2-20mm
- Slice width range: 230-350mm
Physical Parameters
- Weight range: 60-217.05kg (net weight)
- Package dimensions: Compact to large-scale configurations available
Application Recommendations
By Processing Requirements
- Large-scale processing: HB-350/HB-330A (wide slice width, high power)
- Medium-scale operations: HB-330 (balanced performance)
- Small-scale applications: HB-300 (compact design)
- Space-efficient solutions: HB-320 (optimized footprint)
Selection Considerations
- Production volume - Choose capacity based on daily processing requirements
- Space constraints - Consider workshop layout and equipment footprint
- Power availability - Match equipment voltage requirements with facility infrastructure
- Material characteristics - Select appropriate slice thickness and width parameters
Note: All specifications are subject to technical updates. Please confirm parameters with latest product documentation.
